125 m/y j'ade

Shipyard:

CRN S.p.A.

Model:

CRN 60 MT

Yard ID number:

CRN 125

Hull/superstructure:

Steel / Aluminium

Type:

Displacement hull

Loa:

58,2 m

Lbp:

47,00 m

Moulded beam:

10.20 m

Moulded depth:

5.50 m

Ponor:

3.00 m

Full load displacement:

775 t

Deadweight:

125 t

Guest:

N° 10 (4 double cabins + 1 owner suite)

Crew:

N° 14 persons

Kapacita nádrže pohonnej hmoty:

115'000 lt

Kapacita čerstvej vody:

20'000 lt

Fresh water production:

18'000 lt/day

Engine:

2XMTU 12V4000M61 1500 kW @1800rpm

Main generator:

2x KOHLER 200 kW 380V 50Hz

Emergency generator:

1x CATERPILLAR C4.4 93 kW 380v 50Hz

Max speed (Half load):

16 knots

Cruising speed (@ 85%MCR):

14 knots

Exterior design:

ZUCCON INTERNATIONAL PROJECT

Interior design:

ZUCCON INT. PROJECT + CRN INTERIOR and DESIGN

Classification:

Lloyd's Register of Shipping LR 100 - A1 - SSC - Y", MONO, G6, LMC MCA LY2 compliance"

Range @ 14 knots:

3'000 nm

Max noise @ Cruising speed in saloons:

60 dB(A)

Max noise @ Cruising speed in rooms:

55 dB(A)

Helicopter platform:

SUITABLE FOR 1500 KG HELICOPTER

Naval architecture:

CRN ENGINEERING
